Electricity Meter Interface 2, P1
Real-time measurement and reporting of power consumption
The Electricity Meter Interface 2, P1 is an external meter interface customized for power meters with a P1 port, enabling your customers to track their electricity consumption remotely.
This Zigbee end device is compatible with most electricity meters with an enabled P1 port and is powered by the P1 interface and uses minimal energy.
With P1 being the new standard interface for modern meters in many European countries, the Electricity Meter Interface 2, P1 is a central addition to any smart energy management solution.
The interface collects information and readings from the meter and sends the data via Zigbee communication to a gateway. The collected data can then be visualized on a display, such as an app or website, available to your customers.
Facilitate energy optimization through load-shifting
Besides energy awareness, the consumption data can be used for advanced load-shifting, helping move electricity usage to off-peak hours where electricity is cheaper and consumption places less stress on the power grid.
Easy integration and secure data communication
The Electricity Meter Interface 2, P1 is easily installed and integrated. It just needs to be plugged into an installed electronic meter.
Data collected from the electricity meter interface can be communicated to an app or a website via a Zigbee gateway. The Zigbee profile ensures a high level of security to protect personal data and prevent hacking.
Furthermore, the electricity meter interface is OTA (over-the-air) upgradeable which increases the longevity of the product and makes it easy to upgrade firmware remotely.
Compatible meters
The Electricity Meter Interface 2, P1 works with most modern meters but there could be local specifications to be aware of.
Below is a list of electricity meters that we have successfully tested the Electricity Meter Interface 2, P1 with. Please note that we can guarantee full functionality only with meters on this list.
Compatible meters:
- Aidon 7550
- Iskra AM550
- Landis & Gyr E350
- Landis & Gyr E360
- Kaifa MA105C
- Kaifa MA304
- Sagemcom MT212
- Sagemcom MS212
- Kamstrup Omnia E-meter (no support for Kamstrup Omnipower)
